POLYSERVICE P 30 HF-S
Type: P 30 HF-S
Manufacturer: POLYSERVICE
Subgroup: Barrel-polishing machine
Year: 2016
Stock: 023557
POLYSERVICE P 30 HF-S is a barrel‑polishing machine designed for precision, high accuracy and reliability. Internal diameter 440 mm, volume 30 l (useful ~50%); workpieces Ø 2–80 mm, lengths 2–150 mm. Rotation speed 2880 t/min; voltage 3×380 V 50 Hz; installed power 1.4 kW; machine weight ~150 kg; dimensions L900×W800×H1300 mm. Enables tight tolerances; typical applications: automotive, watchmaking, tooling, aerospace, medical.
Technical specifications are subject to change without notice
| Execution: barrel-burnishing | |
| Number of tanks | 1 |
| Circlon-Verfahren (Ringform) | |
| Behältergrösse: | |
| Internal diameter | 440 mm |
| Volume | 30 l |
| Useful volume approximate | 50 % |
| Work-pieces: | |
| diameter min. | 2 mm |
| max. diameter | 80 mm |
| Length from | 2 - 150 mm |
| Rotation speed | 2880 t/min |
| Voltage 50 Hz 3x | 380 Volt |
| Installed power | 1.4 kW |
| Machine's weight about | 150 kg |
| Overall dimensions machine: | |
| Length | 900 mm |
| Width | 800 mm |
| Height | 1300 mm |
