AVEREX HS-450i is a 4-axis machining center designed to deliver precision, high accuracy and reliability. Longitudinal travel (X) 640 mm, transversal travel (Y) 610 mm, vertical travel (Z) 680 mm; workpiece height 1000 mm, diameter 785 mm, maximum workpiece weight 550 kg; table divisions (C) 0.001°. Rapid traverse 60 m/min on X, Y and Z axes; machine weight about 11,645 kg; overall dimensions 4,730 x 2,260 x 2,600 mm (L x W x H). Enables tight tolerances and is suited to automotive, watchmaking, machine tools, aerospace and medical sectors.
Technical specifications are subject to change without notice
| Longitudinal travel (X-axis) | 640 mm |
| Transversal travel (y-axis) | 610 mm |
| Vertical travel (z axis) | 680 mm |
| Dimension of the workpice: | |
| Height | 1000 mm |
| Diameter | 785 mm |
| Table divisions (C) | 0.001 ° |
| Pallets chanching device: | |
| Maximum workpiece weight | 550 kg |
| Rapid traverse: long. | 60 m/min |
| Rapid traverse: transversal | 60 m/min |
| Rapid traverse: vertical | 60 m/min |
| Machine's weight about | 11645 kg |
| Overall dimensions machine: | |
| Length | 4730 mm |
| Width | 2260 mm |
| Height | 2600 mm |
