FISCHER GEORG +GF+ LASER P 600 5AX
Type: LASER P 600 5AX
Manufacturer: FISCHER GEORG +GF+
Group: Laser marking machine
Subgroup: Laser marking machine
Control: PC-Control
Year: 2015
Stock: 023307
FISCHER GEORG +GF+ LASER P 600 5AX is a Laser marking machine designed for precision, high accuracy and reliability. Marking field 160 x 160 mm; travels: X 600 mm, Y 460 mm, Z 830 mm. Voltage 50 Hz 3x 400 V; installed power 4 kW; machine weight about 5000 kg; overall dimensions L 2050 x W 2280 x H 2770 mm. Achieves tight tolerances; typical applications: automotive, watchmaking, machine tools, aerospace, medical
| Marking / labelling dimension: | |
| Length | 160 mm |
| Width | 160 mm |
| Travels: | |
| X axis | 600 mm |
| Y axis | 460 mm |
| Z axis | 830 mm |
| Voltage 50 Hz 3x | 400 Volt |
| Installed power | 4 kW |
| Machine's weight about | 5000 kg |
| Overall dimensions machine: | |
| Length | 2050 mm |
| Width | 2280 mm |
| Height | 2770 mm |

Need Assistance? Just WhatsApp Us!
Machine : winXP_LMCS_3.1.107
LaserCAM : Release V05 SR12.22 / Build 1.1.1071
