| Pressure | 25 to |
| Total stroke | 150 mm |
| Execution: 4 columns | |
| Table surface: | |
| Length | 450 mm |
| Width | 400 mm |
| Slide diameter | 120 mm |
| slide bore diameter | 38 mm |
| Distance from table to | |
| slide-nose: min. | 120 mm |
| max | 270 mm |
| Passage between columns: | |
| longitudinal | 500 mm |
| Lateral | 200 mm |
| Voltage 50 Hz 3x | 380 Volt |
| Total power required | 10.20 CV |
| Machine's weight about | 1750 kg |
| Overall dimensions machine: | |
| Length | 1500 mm |
| Width | 1100 mm |
| Height | 2700 mm |
| Various accessories: | |
| Security/savety device | |
| Foot pedal |
