NAKAMURA-TOME NTRX 300 is a machining and turning center from bar, engineered for precision, high accuracy and reliable production. Main capacities: 6 axes (5 simultaneous), Z travel 1125 mm, X 700 mm, Y ±125 mm, B tilt 225°, C 360° resolution 0.001; workpieces up to 1100 mm length and Ø 640 mm; tool magazine 40 stations, tool Ø max 90 mm, tool length 300 mm. Technical specs: spindle nose Capto C6, main spindle up to 4500 rpm, milling spindle up to 8000 rpm, spindle motor 15/11 kW, rapid traverse 36 m/min, air 5–7 bar, 3x400 V 50 Hz, total power 65.1 kVA, weight ~18000 kg, footprint 4530×2670×2615 mm. Accessories: coolant system, paper filtration, toolholder set, milling cutters, drills, lamp, oil‑mist extractor, bar loader. Achieves tight tolerances; suited for automotive, aerospace, medical, watchmaking and machine‑tool sectors.

Technical specifications are subject to change without notice
