STÖCKEL FNX 640 ST-2
Download technical sheet (PDF)
Need Assistance? Just WhatsApp Us!
| Table length | 600 mm |
| Table width | 400 mm |
| Longitudinal travel (X-axis) | 780 mm |
| Cross travel (z-axis) | 375 mm |
| vertical travel (Y-axis) | 680 mm |
| Table load max. | 300 kg |
| Grinding length | 600 mm |
| Grinding width | 400 mm |
| Grinding height over table | 530 mm |
| Table speeds: | |
| up to | 35 m/min |
| Voltage 50 Hz 3x | 400 Volt |
| Grinding spindle motor | 7.5 kW |
| Machine's weight about | 3600 kg |
| Overall dimensions machine: | |
| Length | 3000 mm |
| Width | 2500 mm |
| Height | 2300 mm |
| Various accessories: | |
| Paper filtration system | |
| Swivellable redressing device | |
| Rinsing Guns | |
| Electronic balancing device | |
| Oil mist extractor |
STÖCKEL FNX 640 ST-2 is a NC Surface grinder, engineered for precision, high accuracy and reliability. Capacities: grinding length 600 mm, grinding width 400 mm, grinding height over table 530 mm; table speeds up to 35 m/min. Main technical specifications: grinding spindle motor 7.5 kW; voltage 50 Hz 3x 400 V; machine weight approx. 3600 kg; overall dimensions L 3000 × W 2500 × H 2300 mm. Delivers tight tolerances and is suited to applications in automotive, aerospace, machine tools, medical and watchmaking.
Technical specifications are subject to change without notice
