SCHAUBLIN 70 is a Toolmakers lathe designed for precision, high accuracy and reliability. Capacities: centre height 70 mm, distance between centres 275 mm, swing over cross‑slide 85 mm, swing over bed 155 mm, spindle hole 12 mm. Specs: machine weight approx. 25 kg; dimensions L700×W350×H250 mm. Inner taper / collet: type 12 W. Delivers tight tolerances; suited to watchmaking, toolmaking, precision components, aerospace and medical sectors
| Centre height | 70 mm |
| Distance between centres | 275 mm |
| Swing over cross-slide | 85 mm |
| Swing over bed | 155 mm |
| Spindle hole | 12 mm |
| Inner taper type | 12 W |
| Machine's weight about | 25 kg |
| Overall dimensions machine: | |
| Length | 700 mm |
| Width | 350 mm |
| Height | 250 mm |
| Without rear drive |
