OKUMA LB 200 M is a CNC turning lathe for high‑precision machining, accuracy and reliable operation. Capacities: turning Ø over cross‑slide 420 mm; swing over bed 530 mm; spindle hole 53 mm; max Ø 300 mm; travels Z 335 mm, X 180 mm. Specs: rapid traverse X 25 m/min, Z 30 m/min; spindle speeds 50–6000 t/min; 3x400 V 50 Hz; total power 16 kVA; weight ≈3300 kg; dims 2035×1720×1700 mm. Equipment: 12‑position fixed‑tool turret; tailstock Morse 4, spindle stroke 80 mm, Ø 55 mm. Enables tight tolerances; typical sectors: automotive, aerospace, medical, machine building.
| Turning diameter over cross-slide | 420 mm |
| Swing over bed | 530 mm |
| Spindle hole | 53 mm |
| Max. turning diameter | 300 mm |
| Travels: | |
| Longitudinal travel (Z-axis) | 335 mm |
| Transversal strocke (X axis) | 180 mm |
| Rapid traverse X | 25 m/min |
| Rapid traverse Z | 30 m/min |
| Turret slide: | |
| Fixed tools turret | 12 |
| Main spindle: | |
| Spindle speeds: | |
| stepless | |
| from | 50 t/min |
| up to | 6000 t/min |
| Tailstock: | |
| Morse taper | 4 CM |
| Spindle stroke | 80 mm |
| Spindle diameter | 55 mm |
| Voltage 50 Hz 3x | 400 Volt |
| Total power required | 16 kVA |
| Machine's weight about | 3300 kg |
| Overall dimensions machine: | |
| Length | 2035 mm |
| Width | 1720 mm |
| Height | 1700 mm |
