023338 - TURBO SEPARATOR MZA-TSS.6122
Download technical sheet (PDF)
Need Assistance? Just WhatsApp Us!
TURBO SEPARATOR MZA-TSS.6122 is a Cooling fluid purging unit engineered for precision, high accuracy and reliability. Capacities: total 1000 l; tank 140 l; filling quantity max. 35 kg; flow rate 120 l/min; basket speed 3200 t/min. Voltage: 50 Hz 3x 400 V. Overall dimensions: L 1800 mm x W 1250 mm x H 1800 mm. Designed to purify machining fluids; ideal for automotive, machine tools, aerospace, medical and watchmaking sectors to achieve tight tolerances.
Centrifuge T22 Rotor capacity 22 l
Rotor: aluminum, for pH values 6.5 - 9.5
Sludge capacity 35 kg
Contaminated coolant tank approx. 140 l
Clean coolant tank approx. 1000 l
Supply pump 120 l/min at 16 bar
High-pressure pump 70 l/min at 40 bar
Immersion recooler 8.7 kW
| Filling quantity max. | 35 kg |
| Total Capacity | 1000 l |
| Tank contenance | 140 l |
| Basket speed | 3200 t/min |
| Capacity | 120 l/min |
| Voltage 50 Hz 3x | 400 Volt |
| Overall dimensions machine: | |
| Length | 1800 mm |
| Width | 1250 mm |
| Height | 2100 mm |
