CITIZEN CINCOM M-16
Type: M-16
Manufacturer: CITIZEN CINCOM
Group: CNC automatic lathe
Subgroup: CNC automatic lathe
Year: 2001
Stock: 023501
CITIZEN CINCOM M-16 is a CNC automatic lathe engineered for precision, high accuracy and reliable operation. It features a total of 13 axes, max. turning diameter 16 mm, turning length 200 mm and internal spindle diameter 20 mm; main and counter spindles up to 12,000 rpm, driven tools up to 8,000 rpm; C‑axis resolution 0.001°. Key specs: spindle motor 2.2 kW, total power required 8 kVA, machine weight approx. 2,900 kg, overall dimensions L2450×W1320×H1700 mm; revolver turret with 10 tools. Built for high-precision production, it achieves tight tolerances and suits automotive, watchmaking, machine tool, aerospace and medical applications.
| Number of axis total | 13 |
| Max. turning diameter | 16 mm |
| Turning length | 200 mm |
| Internal spindle diameter | 20 mm |
| Spindle speeds: | |
| stepless | |
| up to | 12000 t/min |
| Carriage: | |
| Back spindle: | |
| speeds: | |
| up to | 12000 t/min |
| Spindle positioning increment | ° |
| Turret slide: | |
| number of tools | 10 |
| Spindle speeds (turning tools) | 8000 t/min |
| C axis (spindle,resolution) | 0.001 ° |
| Spindle motor | 2.2 kW |
| Total power required | 8 kVA |
| Machine's weight about | 2900 kg |
| Overall dimensions machine: | |
| Length | 2450 mm |
| Width | 1320 mm |
| Height | 1700 mm |
| Various accessories: | |
| Bar feeder | |
| Manufacturer | LNS |
| Type | EXPRESS - 220 |
| year of manufacture | 2007 |
| Coolant system | |
| Oil mist extractor |
