CHRISTEN 1-32/100A
Type: 1-32/100A
Manufacturer: CHRISTEN
Subgroup: Drill grinder
Stock: 023233
Download technical sheet (PDF)
CHRISTEN 1-32/100A is a Drill grinder engineered for precision, high accuracy and reliable performance. Capacities: drills Ø 1–32 mm, point angles 60°–180°; grinding wheel Ø150 mm, width 40 mm, bore 50 mm, speeds up to 2800 rpm. Technical specs: power 1 CV; weight ≈450 kg; overall L800×W750×H1300 mm. Equipment: lamp, coolant system and plexi splash‑guard. Delivers tight tolerances; suited to automotive, toolmaking, aerospace and medical sectors.

Min. drill capacity 1 mm
Max. drill capacity 32 mm
Spitzwinkel min. 60 °
max. 180 °
Diameter of grinding wheel 150 mm
Width of the grinding wheel 40 mm
Drilling cap. of grind.wheel 50 mm
Grinding wheel speeds:
up to 2800 t/min
Power 1 CV
Machine's weight about 450 kg
Overall dimensions machine:
Length 800 mm
Width 750 mm
Height 1300 mm
Various accessories:
Lamp
Coolant system
Plexi splash-guard
