POLYSERVICE P 30 HF-A
POLYSERVICE P 30 HF-A is a barrel-polishing machine designed for precision finishing, offering high accuracy and reliable operation. Capacity: internal tank Ø 440 mm, volume 30 l (useful filling ~50%); workpieces Ø 2–80 mm, lengths 2–150 mm. Technical specifications: rotation speed 2880 t/min; voltage 50 Hz 3x 380 V; installed power 1.2 kW; machine weight approx. 150 kg; overall dimensions L900 × W800 × H1300 mm. Enables achievement of tight tolerances in applications requiring precision components.
Technical specifications are subject to change without notice
| Execution: barrel-burnishing | |
| Number of tanks | 1 |
| Circlon-Verfahren (Ringform) | |
| Behältergrösse: | |
| Internal diameter | 440 mm |
| Volume | 30 l |
| Useful volume approximate | 50 % |
| Work-pieces: | |
| diameter min. | 2 mm |
| max. diameter | 80 mm |
| Length from | 2 - 150 mm |
| Rotation speed | 2880 t/min |
| Voltage 50 Hz 3x | 380 Volt |
| Installed power | 1.2 kW |
| Machine's weight about | 150 kg |
| Overall dimensions machine: | |
| Length | 900 mm |
| Width | 800 mm |
| Height | 1300 mm |
