ABA EL 806 is a NC Surface grinding machine, built for precision, high accuracy and reliability. Capacities: table 800×500 mm; grinding 800×600×500 mm; table load 800 kg; travels X1100 Y600 Z530 mm. Wheel Ø400×100 mm (bore127), 1000–2600 rpm, spindle motor 11 kW, 3×380V; table speeds 2–35 m/min, cross‑feed ≤5 m/min, vertical feed 1–3000 mm/min (res. 0.001 mm). Accessories: diamond dresser on table, lamp, set of grinding wheels, electronic handwheel. Achieves tight tolerances; typical sectors: automotive, aerospace, machine tools, medical, watchmaking.
| Table length | 800 mm |
| Table width | 500 mm |
| Grinding length | 800 mm |
| Grinding width | 600 mm |
| Grinding height | 500 mm |
| Table load max. | 800 kg |
| Longitudinal travel (X-axis) | 1100 mm |
| Transversal travel (y axis) | 600 mm |
| Vertical travel (z axis) | 530 mm |
| Automatic cross-feed: | |
| stepless | |
| from | m/min |
| up to | 5 m/min |
| Table speeds: | |
| stepless | |
| from | 2 m/min |
| up to | 35 m/min |
| Automatic vertical feed: | 0.001 |
| from | 1 mm/min |
| up to | 3000 mm/min |
| Diameter of grinding wheel | 400 mm |
| Width of the grinding wheel | 100 mm |
| Wheel int. diameter | 127 mm |
| Grinding wheel speeds: | |
| stepless | |
| from | 1000 t/min |
| up to | 2600 t/min |
| Voltage 50 Hz 3x | 380 Volt |
| Grinding spindle motor | 11 kW |
| Machine's weight about | 5400 kg |
| Overall dimensions machine: | |
| Length | 3400 mm |
| Width | 2860 mm |
| Height | 2600 mm |
| Various accessories: | |
| Diamond dressing device on table | |
| Lamp | |
| Set of grinding wheels | |
| Handwheel electroinic |
