PAMA SPEEDCENTER is a 5-axis machining center designed for precision, high accuracy and reliability. Travels X2000 Y1600 Z1800 mm; max Ø1550 mm; automatic pallet changer 4 pallets; max workpiece 3000 kg; central bore 22H7; tool magazine 306 places (35 kg). Spindle ISO50 0–4000 rpm, spindle motor 37 kW, torque 162 Nm, accel. 4 m/s; air 4 bar; 3x400V 50Hz; noise 78 dB(A). High-pressure coolant 30 bar; Renishaw touch probe. Achieves tight tolerances; typical sectors: automotive, aerospace, medical.
| Time under power | 52198 Heures |
| Working time | 13872 Heures |
| Longitudinal travel (X-axis) | 2000 mm |
| Transversal travel (y-axis) | 1600 mm |
| Vertical travel (z axis) | 1800 mm |
| Dimension of the workpice: | |
| Diameter | 1550 mm |
| B axis | 360 ° |
| Pallets chanching device: | |
| Automatic pallet change-unit (number of paletts) | 4 |
| Length | 1000 mm |
| Width | 1000 mm |
| central bore | 22H7 mm |
| Maximum workpiece weight | 3000 kg |
| Tool magazine number of tool places | 306 |
| Max. tool-weight | 35 kg |
| Spindle nose: ISO | 50 DIN69871/2 |
| Spindle speeds: | |
| stepless | |
| from | 0 t/min |
| up to | 4000 t/min |
| Torque max. | 162 Nm |
| Acceleration | 4 m/s |
| Air connect | 4 bar |
| Voltage 50 Hz 3x | 400 Volt |
| Spindle motor | 37 kW |
| Noise level | 78 dB (A) |
| Various accessories: | |
| High pression colant device | 30 bar |
| Touch Probe Renishaw |
