HAUSER S 35-400 is a CNC jig grinder engineered for precision, high accuracy and reliable performance. Working capacities: table 600 x 380 mm with 6 T-slots 10 mm at 50 mm spacing, max table load 200 kg; travels X 500 mm, Y 300 mm, vertical slide 450 mm; passage spindle–table 485 mm; max grinding diameter 230 mm (360 mm with intermediate plate); spindle nose stroke 340 mm; taper grinding up to 16°. Key specs: grinding spindle travel stepless 1–110 mm, vertical speed 1–12 m/min stepless, planetary (C) 5–250 t/min stepless, feeds X/Y 0–12 m/min, W 900 mm/min; spindle motor 7.5 kW; supply 3x 380 V 50 Hz; machine weight ≈ 4000 kg; dimensions 2700×1700×2850 mm. Achieves tight tolerances; typical applications: automotive, watchmaking, machine tools, aerospace, medical.
| 1 column execution | |
| Table: | |
| Table length | 600 mm |
| Table width | 380 mm |
| T-channel width | 10 mm |
| Number of spline | 6 |
| Distance of the T-slots | 50 mm |
| Table load max. | 200 kg |
| Carriage: | |
| Longitudinal travel (X-axis) | 500 mm |
| Transversal travel (y-axis) | 300 mm |
| Travel of the vertical slide | 450 mm |
| Passage from grinding motor to table | 485 mm |
| Max. grinding diameter | 230 mm |
| with display-plate | 360 mm |
| Stroke of spindle-nose | 340 mm |
| Max. angle with taper grinding: | |
| up to | 16 ° |
| Vertical travel of grinding spindle: | |
| stepless from | 1 mm |
| up to | 110 mm |
| Travel speeds: | |
| stepless | |
| from | 1 m/min |
| up to | 12 m/min |
| Planetary motion speeds: c axis | |
| stepless | |
| from | 5 t/min |
| up to | 250 t/min |
| Feeds: | |
| X axis | 0 - 12 m/min |
| Y axis | 0 - 12 m/min |
| W axis | 900 mm/min |
| Voltage 50 Hz 3x | 380 Volt |
| Spindle motor | 7.5 kW |
| Machine's weight about | 4000 kg |
| Overall dimensions machine: | |
| Length | 2700 mm |
| Width | 1700 mm |
| Height | 2850 mm |
