HAUSER S 35-400 is a CNC jig grinder for precision, high accuracy and reliability. Capacities: table 600×380 mm, X500 Y300, vertical slide 450 mm, spindle‑to‑table 485 mm, max grinding Ø 230 mm (360 with plate), spindle nose stroke 340 mm, taper up to 16°. Specs: spindle vertical travel 1–110 mm stepless, travel speeds 1–12 m/min, planetary C 5–250 t/min, 3×380 V 50 Hz, total power 10 CV, weight ≈4000 kg, footprint 2700×1700×2850 mm. Accessories: coolant, paper filtration, lamp, MSS, oil‑mist extractor, CBN redresser HF, toolchanger 12 EROWA. Suited for tight tolerances in automotive, watchmaking, toolmaking, aerospace and medical sectors.
Technical specifications are subject to change without notice
| 1 column execution | |
| Table length | 600 mm |
| Table width | 380 mm |
| Longitudinal travel (X-axis) | 500 mm |
| Transversal travel (y-axis) | 300 mm |
| Regolazione angolare del cannotto | ° |
| Travel of the vertical slide | 450 mm |
| Passage from grinding motor to table | 485 mm |
| Max. grinding diameter | 230 mm |
| with display-plate | 360 mm |
| Stroke of spindle-nose | 340 mm |
| Max. angle with taper grinding: | |
| up to | 16 ° |
| Vertical travel of grinding spindle: | |
| stepless from | 1 mm |
| up to | 110 mm |
| Travel speeds: | |
| stepless | |
| from | 1 m/min |
| up to | 12 m/min |
| Planetary motion speeds: c axis | |
| stepless | |
| from | 5 t/min |
| up to | 250 t/min |
| Voltage 50 Hz 3x | 380 Volt |
| Total power required | 10 CV |
| Machine's weight about | 4000 kg |
| Overall dimensions machine: | |
| Length | 2700 mm |
| Width | 1700 mm |
| Height | 2850 mm |
| Various accessories: | |
| Coolant system | |
| Paper filtration system | |
| Lamp | |
| MSS Multi-Sensoric-System | |
| Oil mist extractor | |
| CBN Redresser with HF-drive | |
| Tool changer: (number of tools) | 12 |
| Type | EROWA |
