SA-12 is a CNC automatic lathe engineered for high precision, accuracy and reliability. Working capacities: max turning Ø 16 mm, max drilling Ø 7 mm, max threading up to M6; max tapping length 85 mm, back-machining length max 85 mm. Key specs: spindle stepless 500–12,000 rpm, spindle power 2.2 kW (2.2/3.7 kW noted), C-axis resolution 15°, back spindle 500–8,000 rpm, rapid traverse 18 m/min, cutting speed 10,000 mm/min; supply 3x400 V 50 Hz, total power 6 kVA, air 5 bar; weight ~1700 kg, footprint 2090×770×1660 mm. Accessories: lamp and 80 l coolant system. Delivers tight tolerances; suited to automotive, watchmaking, machine tools, aerospace and medical sectors.
| Number of axis total | 4 |
| Number of axis simultaneous | |
| Number of spindles | 2 |
| Max. turning diameter | 16 mm |
| Max. drilling diameter | 7 mm |
| Max. threading diameter | 6 M |
| Spindle speeds: | |
| stepless | |
| from | 500 t/min |
| up to | 12000 t/min |
| Spindle power | 2.2 kW |
| C axis (spindle,resolution) | 15 ° |
| Back spindle: | |
| speeds: | |
| from | 500 t/min |
| up to | 8000 t/min |
| Max. tapping length | 85 mm |
| Thread drill diameter | 3 M |
| Back machining workpiece length max. | 85 mm |
| Tool-holder: | |
| Turning tools | 6 pce |
| Drilling tools | 2 pce |
| Spindle speeds (turning tools) | 4000 t/min |
| Counter-operation: | |
| number of tools | 4 |
| Rapid traverse: | 18 m/min |
| Cutting speed | 10000 mm/min |
| Voltage 50 Hz 3x | 400 Volt |
| Spindle motor | 2.2 / 3.7 kW |
| Power of back spindle | 0.5 kW |
| Air connect | 5 bar |
| Total power required | 6 kVA |
| Machine's weight about | 1700 kg |
| Overall dimensions machine: | |
| Length | 2090 mm |
| Width | 770 mm |
| Height | 1660 mm |
| Various accessories: | |
| Lamp | |
| Coolant system | 80 l |
