HAUSER S 40-CNC 311 is a CNC jig grinder for precision, high accuracy and reliability. Table 770×630 mm, table load 500 kg; travels X650 Y450 Z500 mm, spindle stroke 130 mm; max grinding Ø 230 mm (360 with display-plate); passage between columns 750 mm; taper up to 16°; Z 0–140 mm. C‑axis 5–250 t/min; grinding spindle 4,500–80,000 t/min (air turbine 160,000); 3×380 V 50 Hz, 8 kW; weight ≈4000 kg; dims 4000×3600×3200 mm. Delivers tight tolerances; suitable for automotive, watchmaking, machine tools, aerospace and medical.
| 2 columns execution | |
| Table length | 770 mm |
| Table width | 630 mm |
| Table load max. | 500 kg |
| Longitudinal travel (X-axis) | 650 mm |
| Transversal travel (y-axis) | 450 mm |
| Vertical travel (z axis) | 500 mm |
| Spindle stroke | 130 mm |
| Distance from spindle-center to vertical slide | 600 mm |
| Max. grinding diameter | 230 mm |
| with display-plate | 360 mm |
| Passage between the columns | 750 mm |
| Max. angle with taper grinding: | |
| up to | 16.0 ° |
| Stroke length Z, infinitely adjustable | 0 - 140 mm |
| Planetary motion speeds: c axis | |
| stepless | |
| from | 5 t/min |
| up to | 250 t/min |
| Possible grinding-spindle speeds: | |
| stepless | |
| from | 4500 t/min |
| up to | 80000 t/min |
| With air-turbine max. | 160000 t/min |
| Voltage 50 Hz 3x | 380 Volt |
| Total power required | 8 kW |
| Machine's weight about | 4000 kg |
| Overall dimensions machine: | |
| Length | 4000 mm |
| Width | 3600 mm |
| Height | 3200 mm |
