ETALON Derby 454
Type: Derby 454
Manufacturer: ETALON
Group: Measuring machine
Subgroup: Measuring machine
Year: 2001
Stock: 021962
ETALON Derby 454 is a Measuring machine offering exceptional precision, high accuracy and reliability. Measuring ways: longitudinal 457 mm, transversal 508 mm, vertical 483 mm. Table 750×550 mm; workpieces up to 750×559×483 mm, table load max 227 kg. Voltage 230 V, air connect 4.8–8.3 bar; machine weight about 600 kg; overall dimensions 1000×900×2400 mm. Designed to achieve tight tolerances; suitable for automotive, watchmaking, machine tools, aerospace and medical sectors.
| Measuring ways: | |
| longitudinal | 457 mm |
| transversal | 508 mm |
| Vertical | 483 mm |
| Table size: | |
| Length | 750 mm |
| Width | 550 mm |
| Workpiece dimensions: | |
| Length | 750 mm |
| Width | 559 mm |
| Height | 483 mm |
| Table load max. | 227 kg |
| Voltage | 230 Volt |
| Air connect | 4.8 - 8.3 bar |
| Machine's weight about | 600 kg |
| Overall dimensions machine: | |
| Length | 1000 mm |
| Width | 900 mm |
| Height | 2400 mm |
