FEINTOOL GKP-F-40
Download technical sheet (PDF)
Need Assistance? Just WhatsApp Us!
FEINTOOL GKP-F-40 is a hydraulic fineblanking press for precision, high accuracy and reliability. 40 t slide pressure; hydraulic counterpressure 0.5–12 t; hold down 2–12 t; table 300×280 mm; 45–110 strokes/min; tool height 110–180 mm; T‑slot 12 mm; max thickness 4 mm. 3×380 V 50 Hz; main motor 3 kW; weight ≈2500 kg; dims 1835×1500×1800 mm; electric cabinet 900×400×1800 mm. Accessories: forward feed (max band 100 mm), workpiece counter. Achieves tight tolerances; sectors: automotive, watchmaking, machine tools, aerospace, medical.
| Slide pressure | 40 to |
| Hydraulic counterpressure | 0.5 - 12 to |
| Hydraulic hold down | 2 - 12 to |
| Fixed table: length | 300 mm |
| Width | 280 mm |
| Number of strokes: | |
| stepless | |
| from | 45 c/min |
| up to | 110 c/min |
| Tool height: | |
| from | 110 mm |
| up to | 180 mm |
| T-channel width | 12 mm |
| Maximum thickness of material | 4 mm |
| Voltage 50 Hz 3x | 380 Volt |
| Main motor | 3 kW |
| Machine's weight about | 2500 kg |
| Overall dimensions machine: | |
| Length | 1835 mm |
| Width | 1500 mm |
| Height | 1800 mm |
| Dimensions electric cabinet: | |
| Length | 900 mm |
| Width | 400 mm |
| Height | 1800 mm |
| Various accessories: | |
| Forward feed device | |
| Max. bandwidth | 100 mm |
| Workpiece counter |
