021903 - CARNAGHI PIETRO AFT 16 TM/SH
Download technical sheet (PDF)
Message us on WhatsApp
| Surface plate diameter | 1000 mm |
| Swing diameter | 1650 mm |
| Max. turn height | 1100 mm |
| Travels: | |
| X axis | -1010 / +1010 mm |
| Y axis | 600 mm |
| Z axis | 1250 mm |
| C axis | 360 ° |
| Tool magazine number of tool places | 40 |
| Spindle nose: | KM63 |
| Tool section | 40 mm |
| Milling cutter speeds: | |
| stepless | |
| from | 10 t/min |
| up to | 3000 t/min |
| Torque max. | 1000 Nm |
| Power | 31 kW |
| Table load max. | 3000 kg |
| Table speeds: | |
| stepless | |
| from | 5 t/min |
| up to | 800 t/min |
| Engine power | 60 kW |
| Feeds | 0.1 - 3000 mm/min |
| Rapid traverse: | 10 m/min |
| Voltage 50 Hz 3x | 400 Volt |
| Total power required | 196 kW |
| Machine's weight about | 35000 kg |
| Overall dimensions machine: | |
| Floor space required: | 12500 |
| Length | 7225 mm |
| Width | 8735 mm |
| Various accessories: | |
| Coolant system | |
| Set of toolholders | |
| Chip conveyor | |
| Pallets chanching device: | |
| Pallets: number | 2 |
