FAVRETTO ME-U 500 is a CNC Surface grinder engineered for precision, high accuracy and reliability. Table 5150×800 mm, max table load 1500 kg/m; grinding length 5000 mm; grinding height 700 mm; passage between columns 1000 mm. Grinding wheel Ø457×75 mm, bore 203 mm, fixed speed 1200 t/min; table speed stepless 1–40 m/min; automatic cross feed stepless 5–1500 mm/min; feed motor 11 kW. Machine weight ≈26500 kg; dimensions 12700×3960×3600 mm. Accessories: oil mist extractor, magnetic plate 5000×800 mm, lamp. Achieves tight tolerances; suited to automotive, aerospace, machine tools, medical and watchmaking.
Technical specifications are subject to change without notice
| Table length | 5150 mm |
| Table width | 800 mm |
| Max. permitted table load | 1500 kg/m |
| Grinding length | 5000 mm |
| Grinding height over table | 700 mm |
| Passage between the columns | 1000 mm |
| Grinding wheel: | |
| Diameter | 457 mm |
| Width | 75 mm |
| Bore | 203 mm |
| Grinding wheel speeds fix | 1200 t/min |
| Table speeds: | |
| stepless | |
| from | 1 m/min |
| up to | 40 m/min |
| Automatic cross feed: | |
| stepless | |
| from | 5 mm/min |
| up to | 1500 mm/min |
| Feed motor | 11 kW |
| Machine's weight about | 26500 kg |
| Overall dimensions machine: | |
| Length | 12700 mm |
| Width | 3960 mm |
| Height | 3600 mm |
| Various accessories: | |
| Oil mist extractor | |
| Magnetic plate: | |
| Length | 5000 mm |
| Width | 800 mm |
| Lamp |
