BIGLIA B 42 SM is a CNC turning lathe for precision machining, offering high accuracy and reliability. 2 spindles, 2 turrets (12 pos.), spindle spacing 560 mm; max Ø 200 mm, max length 300 mm, bar Ø max 41 mm. Main spindle 100–5000 rpm 3.7–5.5 kW; X/Z (up)175/305 mm, (low)132/155 mm; C‑axis 0.001°. Equipment: 150 l coolant, IEMCA BOSS 542 bar feeder. Suited to tight tolerances in automotive, aerospace, medical, watchmaking.
| Number of spindles | 2 |
| Number of revolvers | 2 |
| Distance spindle nose | 560 mm |
| Turret slide: | |
| Number of positions turret 1 | 12 |
| Number of positions turret 2 | 12 |
| Driven tools turret 1 | 6 |
| Spindle speeds | 100 - 3000 t/min |
| Tool shank cross section | 20 mm |
| Power of driven tools | 1.5 / 3.7 kW |
| Max. drill capacity | 25 mm |
| Indexing time | 0.4 s |
| Upper turret head: | |
| X axis | 175 mm |
| Z axis | 305 mm |
| Lower turret head: | |
| X axis | 132 mm |
| Z axis | 155 mm |
| Main spindle: | |
| Spindle nose | ASA 5" |
| Spindle hole | 52 mm |
| Inner taper type | DIN 6343 |
| Max. bar diameter | 41 mm |
| Max. turning diameter | 200 mm |
| Maximum turning length | 300 mm |
| C axis (spindle,resolution) | 0.001 ° |
| Spindle speeds: | |
| stepless | |
| from | 100 t/min |
| up to | 5000 t/min |
| Spindle power | 3.7 - 5.5 kW |
| Back spindle: | |
| Spindle nose | ASA 4" |
| Spindle hole | 42 mm |
| max. speed | 5000 t/min |
| Inner taper type | DIN 6343 |
| Max. turning diameter | 150 mm |
| Maximum turning length | 150 mm |
| C axis (spindle,resolution) | ° |
| Rapid traverse X | 12 m/min |
| Rapid traverse Z | 20 m/min |
| Spindle motor | 11 - 15 kW |
| Voltage 50 Hz 3x | 400 Volt |
| Machine's weight about | 4700 kg |
| Overall dimensions machine: | |
| Length | 2500 mm |
| Width | 2000 mm |
| Height | 2100 mm |
| Various accessories: | |
| Lamp | |
| Coolant system | 150 l |
| Bar feeder | IEMCA |
| Type | BOSS 542 |
| Length of bars max. | 3200 mm |
| Bar diameter | 5 - 42 mm |
| Part separating device | |
| Switch cabinet Cooling unit | |
| Status light |
