KASTO SSB 260 VA
Download technical sheet (PDF)
Need Assistance? Just WhatsApp Us!
KASTO SSB 260 VA is a band saw for precision, high accuracy and reliability. Cut range round 10-260 mm, square 260×260 mm; cut length 5-680 mm; feed length 680 mm; blade speed 15-125 m/min; band 4115×41×1 mm. Voltage 3×380 V 50 Hz; power 4/6.5 kW; weight ≈1915 kg; dims L2125×W1930×H2100 mm. Equipment: automatic forward feed, 1 m material support, roller conveyor, coolant, chip conveyor. Achieves tight tolerances; suitable for automotive, machine building, aerospace, medical.
| Cut range: round up to | 10 - 260 mm |
| Square | 260 x 260 mm |
| vertical | |
| hydraulic | |
| Automatic | |
| Cut length: | |
| min. | 5 mm |
| max | 680 mm |
| Max. automatic forward | |
| feed length | 680 mm |
| stepless | |
| from | 15 m/min |
| up to | 125 m/min |
| Band length | 4115 mm |
| Band width | 41 mm |
| Sheet thickness | 1 mm |
| Voltage 50 Hz 3x | 380 Volt |
| Power | 4 / 6.5 kW |
| Machine's weight about | 1915 kg |
| Overall dimensions machine: | |
| Length | 2125 mm |
| Width | 1930 mm |
| Height | 2100 mm |
| Various accessories: | |
| Automatic forward feed | |
| Material bearing lenght | 1 m |
| Roller conveyor | |
| Coolant system | |
| Chip conveyor |
