019353 - WALDRICH COBURG 20-10 FP 280

1 12

Manufacturer: WALDRICH COBURG

Group: Milling machine gantry type

Subgroup: Milling machine gantry type

Type: 20-10 FP 280

Stock: 019353

Request Information

Number of axis total	3
Table length	8000 mm
Table width	2800 mm
Number of T-channels	11
T-channel width	36H8 mm
Distance of the T-slots	250 mm
Travels:
X axis	9000 mm
Y axis	2950 mm
Z axis	1250 mm
W axis	2200 mm
Distance table to spindle max.	2806 mm
Distance between columns	3200 mm
Table load max.	64000 kg
Taper in spindle	60 ISO
Spindle speeds:
number (steps)	16
from	20 t/min
up to	600 t/min
Feeds:
X axis from	5 mm/min
up to	3000 mm/min
Y axis from	5 mm/min
up to	3000 mm/min
Z axis from	5 mm/min
up to	2000 mm/min
W axis from	5 mm/min
up to	750 mm/min
Creep speeds:
X axis	5 - 3000 mm/min
Y axis	5 - 3000 mm/min
Z axis	5 - 2000 mm/min
W axis	5 - 50 mm/min
Voltage 50 Hz 3x	380 Volt
Spindle motor	100 kW
Spindle torque	13000 Nm
Overall dimensions about:
Length	21000 mm
Width	7800 mm
Height	6622 mm
Various accessories:
90° attachment
90° narrow attachment
Vertical extension
Tilting attachment
