HASEGAWA PM 150-01
Download technical sheet (PDF)
Need Assistance? Just WhatsApp Us!
HASEGAWA PM 150-01 is a CNC high-speed milling machine designed for precision, high accuracy and reliability. Working capacities: table 300×260 mm, travels X150 / Y225+50 ATC / Z200 mm, table load 80 kg, spindle‑to‑table 140–340 mm. Key specs: HSK‑E32 taper, spindle 100–30,000 t/min (stepless), spindle motor 3.0/4.5 kW, rapid 30 m/min, total power 12 kVA, dimensions 1750×600×1800 mm, weight ≈2000 kg. Equipment: 17‑pos tool changer, BLUM Z‑Pico automatic tool setting, 120 L coolant, electronic handwheel, full splash cabin, Flash/USB/Ethernet interface, spindle cooling, status light. Enables tight tolerances; typical sectors: automotive, watchmaking, toolmaking, aerospace, medical.
| Table length | 300 mm |
| Table width | 260 mm |
| Longitudinal travel (X-axis) | 150 mm |
| Transversal travel (y axis) | 225+50 ATC mm |
| Vertical travel (z axis) | 200 mm |
| Table load max. | 80 kg |
| Distance from vertical | |
| spindle to table | 140 ~ 340 mm |
| Taper in spindle | HSK-E32 |
| Spindle speeds: | |
| stepless | |
| vertical from | 100 t/min |
| up to | 30000 t/min |
| Tool changer: | |
| number of tools | 17 |
| Rapid traverse: | 30 m/min |
| Milling spindle motor | 3.0 / 4.5 kW |
| Total power required | 12 kVA |
| Machine's weight about | 2000 kg |
| Overall dimensions machine: | |
| Length | 1750 mm |
| Width | 600 mm |
| Height | 1800 mm |
| Various accessories: | |
| Handwheel electroinic | |
| Full splash cabin | |
| Coolant system | 120 ltr. |
| Tool changer: (number of tools) | 17 |
| Automatic setting tool | BLUM Z-Pico |
| Interface: | Flash/USB/Ethernet |
| Interface serial port RS 232-C, V 24 | |
| Spindlecooling | |
| Status light |
