| Number of axis simultaneous | 5 |
| Number of spindles | 1 |
| Table load max. | 800 kg |
| Longitudinal travel (X-axis) | 800 mm |
| Transversal travel (y-axis) | 750 mm |
| Vertical travel (z axis) | 620 mm |
| Dimension of the workpice: | |
| Height | 550 mm |
| Diameter | 500 mm |
| Table divisions (B) | 0,001° ° |
| A axis | 145° (+35/-110°) |
| Table speed | 30 t/min |
| Pallets: | System Staflex |
| numbers | 4 |
| Length | 500 mm |
| Width | 500 mm |
| Transport weight | 200 kg |
| Tool changer: | |
| Number of tools | 60 |
| Tool diameter max. | 120 mm |
| Diameter with free adjacent pockets | 200 mm |
| Tool lenght | 400 mm |
| Max. tool-weight | 15 kg |
| Spindle nose: | HSK-A 100 |
| Spindle speeds: | STEP TEC |
| stepless | |
| up to | 12000 t/min |
| Torque max. | 250 Nm |
| Rapid traverse: | 40 m/min |
| Air connect | 5 bar |
| Voltage 50 Hz 3x | 400 Volt |
| Spindle motor | 40 kW |
| Total power required | 120 kW |
| Machine's weight about | 22000 kg |
| Overall dimensions machine: | |
| Length | 8000 mm |
| Width | 5000 mm |
| Height | 4000 mm |
| Various accessories: | |
| Set of toolholders | |
| Tool break control | |
| Pallets chanching device: | |
| Rotating viewing window |
