ACIERA 22 V is a pillar drilling machine for precision, high accuracy and reliability. Capacities: Ø22/24 mm (steel/cast‑iron); throat 300 mm; spindle stroke 120 mm; table 700×370 mm; travels X/Y/Z 330/210/350 mm. Specs: stepless 275–3600 rpm; spindle motor 2 CV; 3×380 V; weight ~990 kg. Equipment: 2‑axis DRO, coolant prep, lamp, quick‑change, motorized table. Ideal for tight‑tolerance work in automotive, aerospace and medical sectors.
Technical specifications are subject to change without notice
| Table length | 700 mm |
| Table width | 370 mm |
| Clamping surface: | |
| Length | 580 mm |
| Width | 280 mm |
| Drill capacity in steel | 22 mm |
| Drill capacity in cast-iron | 24 mm |
| Depth of throat | 300 mm |
| Drill depth (spindle stroke) | 120 mm |
| Spindle head adjustment | 300 mm |
| Table travels: | |
| Longitudinal travel (X-axis) | 330 mm |
| Transversal travel (y-axis) | 210 mm |
| Vertical travel (z axis) | 350 mm |
| Spindle speeds: | |
| stepless | |
| from | 275 t/min |
| up to | 3600 t/min |
| Voltage 50 Hz 3x | 380 Volt |
| Spindle motor | 2 CV |
| Machine's weight about | 990 kg |
| Overall dimensions machine: | |
| Length | 1100 mm |
| Width | 600 mm |
| Height | 2100 mm |
| Various accessories: | |
| Digital readout number of axis: | 2 |
| Preparation for coolant device | |
| Lamp | |
| Quick change device | |
| Motorized table adjustment |
