SUTHERLAND SD 3.600
Type: SD 3.600
Manufacturer: SUTHERLAND
Subgroup: Hydraulic press
Year: 2001
Stock: 018686
Download technical sheet (PDF)
SUTHERLAND SD 3.600 is a Hydraulic press of high precision, built for superior accuracy and reliability. Working capacities: Pressure 600 to; total stroke 0–305 mm; table 3070×1530 mm; distance from table max 950 mm; lateral passage 1220 mm; slide 3070×1530 mm. Main specs: rapid traverse 296 mm/s, press stroke 10 mm/s, return 380 mm/s; motor power 150 kW; overall dimensions 4250×2100×(5700+900) mm. Designed to achieve tight tolerances; typical applications: automotive, aerospace, machine tools, medical, watchmaking.

Pressure 600 to
Total stroke 0 - 305 mm
Table surface:
   Length 3070 mm
   Width 1530 mm
Distance from table to
   max 950 mm
Passage between supports:
   Lateral 1220 mm
Slide clamping surface:
   Width 3070 mm
   depth 1530 mm
Close traverse speeds:
   Rapid traverse 296 mm/s
   Press stroke 10 mm/s
   Return traverse speeds 380 mm/s
Motor power 150 kW
Overall dimensions machine:
   Length 4250 mm
   Width 2100 mm
   Height (5700+900) mm
