| Centre height | 102 mm |
| Distance between centres | 300 mm |
| Swing over cross-slide | 120 mm |
| Swing over bed | 200 mm |
| Spindle hole | 20 mm |
| Inner taper type | 20 W |
| Taper spindle threaded | |
| Spindle speeds: | |
| stepless | |
| from | 55 t/min |
| up to | 3000 t/min |
| Taper in tailstock: | 2 CM |
| Voltage 50 Hz 3x | 380 Volt |
| Spindle motor | 1.5 CV |
| Machine's weight about | 450 kg |
| Overall dimensions machine: | |
| Length | 1200 mm |
| Width | 600 mm |
| Height | 1400 mm |
| Various accessories: | |
| Base-mounted type: | |
| Knee-operated reversing switch | |
| 2 drawers | |
| Stepless speed variator | |
| Driving system for milling and grinding attachment | |
| Belt-tensioning device for milling/grinding att. | |
| Headstock with reduction gear | |
| Driving plate | |
| Drilling tailstock |
