    FMB Turbo Turbo 3-26


Type: Turbo Turbo 3-26





        Manufacturer: FMB






        Group: Bar feeder/loader







        Subgroup: Bar feeder/loader

















        Year: 2011





      Stock: 022599





            FMB Turbo Turbo 3-26 is a bar feeder/loader of high precision, designed for excellent accuracy and reliable operation. Capacities: bar diameter round 3–26 mm, bar length max 3200 mm, outstanding length min 450 mm, feed range 0–400 mm/s. Specs: max feed force 550 N, voltage 3x400 V 50 Hz, power 2 kW, compressed air 6 bar, weight ~750 kg, dimensions L4700×W700×H1500 mm. Enables tight tolerances; typical applications: automotive, watchmaking, machine tools, aerospace and medical.


| Execution: | |
| righthand | |
| Bar diameter round up | 3 mm |
| up to | 26 mm |
| Length of bars max. | 3200 mm |
| Outstanding length min. | 450 mm |
| Feed range | 0 - 400 mm/s |
| Max. Feed force | 550 N |
| Voltage 50 Hz 3x | 400 Volt |
| Power | 2 kW |
| Compressed air from | 6 bar |
| Machine's weight about | 750 kg |
| Overall dimensions machine: | |
| Length | 4700 mm |
| Width | 700 mm |
| Height | 1500 mm |
