LNS QUICKLOAD SERVO II is a Bar feeder/loader designed for precision, high accuracy and reliability. Execution: righthand; working capacities: round bar diameter from 6 mm up to 80 mm, bar length min. 130 mm, max. 1500 mm, bar weight max. 67 kg. Main technical specifications: loading time 4–12 s, feed range max. 100 m/min, push force max. 167 Nm, voltage 3x 380 V 50 Hz, compressed air from 5 bar; machine weight about 600 kg; overall dimensions L 2050 x W 1800 x H 1700 mm. (No accessories specified). Enables achievement of tight tolerances and is suited to automotive, aerospace, medical, watchmaking and machine tool applications.

Technical specifications are subject to change without notice
