BOEHRINGER / VDF NV 250 T
Download technical sheet (PDF)
Need Assistance? Just WhatsApp Us!
BOEHRINGER / VDF NV 250 T is a CNC vertical turning machine designed for precision machining, high accuracy and reliability. Total axes 4; spindle hole 65 mm; travels Z 260 mm, X 760 mm, Y ±50 mm; rapid traverse X 120 m/min, Z 40 m/min; turret 12 positions VDI 40/DIN 69880. Spindle head A6; stepless up to 4500 t/min; spindle power 31 kW; voltage 50 Hz 3x 400 V; machine weight approx. 8500 kg. Equipment: 3-jaw chuck Ø250 mm with automatic centering, lamp, coolant system, oil mist extractor, automatic loading/unloading unit. Achieves tight tolerances; typical for automotive, aerospace, medical and machine tool sectors
Technical specifications are subject to change without notice
| Number of axis total | 4 |
| Number of spindles | |
| Spindle head | A6 |
| Spindle hole | 65 mm |
| Travels: | |
| Longitudinal travel (Z-axis) | 260 mm |
| Transversal strocke (X axis) | 760 mm |
| Transversal travel (y-axis) | +-50 mm |
| Rapid traverse X | 120 m/min |
| Rapid traverse Z | 40 m/min |
| Turret slide: | |
| Number of positions | 12 |
| Spindle nose: VDI | 40 / DIN 69880 |
| Main spindle: | |
| C axis | |
| Spindle speeds: | |
| stepless | |
| up to | 4500 t/min |
| Spindle power | 31 kW |
| Voltage 50 Hz 3x | 400 Volt |
| Machine's weight about | 8500 kg |
| Various accessories: | |
| 3-jaw chuck diameter | 250 mm |
| Lamp | |
| Coolant system | |
| Oil mist extractor | |
| Automatic loading and unloading unit |
