SCHAUBLIN 13 is a Universal milling machine engineered for precision work, high accuracy and proven reliability. Table 600x210 mm; travels X260, Y150, Z310 mm; spindle-to-table distances 310/410 mm. Spindle stepless 58–2000 rpm, taper 30 ISO; 10 feed steps 12–400 mm/min; rapid traverse 1.2 m/min (long./transv.); 3x380V 50Hz; motor 2.0 CV; total power 3 CV; weight ~700 kg; overall 1100x1000x1550 mm. Accessories: dividing attachment (centre height 105 mm), dividing attachment, vice, set of toolholders, lamp. Delivers tight tolerances; ideal for watchmaking, aerospace, medical, automotive and machine-tool sectors.
Technical specifications are subject to change without notice
| Table length | 600 mm |
| Table width | 210 mm |
| Longitudinal travel (X-axis) | 260 mm |
| Transversal travel (y axis) | 150 mm |
| Vertical travel (z axis) | 310 mm |
| Distance from vertical spindle to table | 310 mm |
| Distance from horizontal spindle to table | 410 mm |
| Spindle speeds: | |
| stepless | |
| from | 58 t/min |
| up to | 2000 t/min |
| Taper in spindle | 30 ISO |
| Feeds steps: | 10 |
| longitudinal from | 12 mm/min |
| up to | 400 mm/min |
| vertical from | 12 mm/min |
| up to | 400 mm/min |
| Rapid traverse: | |
| longitudinal | 1.2 m/min |
| transversal | 1.2 m/min |
| Voltage 50 Hz 3x | 380 Volt |
| Motor output | 2.0 CV |
| Total power required | 3 CV |
| Machine's weight about | 700 kg |
| Overall dimensions machine: | |
| Length | 1100 mm |
| Width | 1000 mm |
| Height | 1550 mm |
| Various accessories: | |
| Dividing attachment: centre height | 105 mm |
| Dividing attachment | |
| Vice | |
| Set of toolholders | |
| Lamp |
