FAVRETTO MB 75 is a Surface grinder with high precision, exceptional accuracy and proven reliability. Capacities: table 750×400 mm; grinding length 750 mm; grinding width 485 mm; grinding height 550 mm; table load 850 kg; travels X750, Y485, Z550 mm. Technical specs: grinding wheel Ø400×100 mm, bore 127 mm; wheel speed from 1400 t/min; grinding spindle motor 11 kW; total installed power 25 kW; supply 3×380 V 50 Hz; table speeds stepless 1–40 m/min; vertical rapid 1.5 m/min; machine weight ~6500 kg; dimensions 3950×2935×2540 mm. Designed to achieve tight tolerances; suitable for automotive, watchmaking, machine tools, aerospace and medical industries.
Technical specifications are subject to change without notice
| Table length | 750 mm |
| Table width | 400 mm |
| Grinding length | 750 mm |
| Grinding width | 485 mm |
| Grinding height | 550 mm |
| Table load max. | 850 kg |
| Longitudinal travel (X-axis) | 750 mm |
| Transversal travel (y axis) | 485 mm |
| Vertical travel (z axis) | 550 mm |
| Automatic cross-feed: | |
| stepless | |
| from | mm |
| up to | 1’400 mm |
| Table speeds: | |
| stepless | |
| from | 1 m/min |
| up to | 40 m/min |
| Automatic vertical feed: | |
| from | mm |
| Vertical rapid traverse | 1.5 m/min |
| Diameter of grinding wheel | 400 mm |
| Width of the grinding wheel | 100 mm |
| Wheel int. diameter | 127 mm |
| Grinding wheel speeds: | |
| from | 1400 t/min |
| Voltage 50 Hz 3x | 380 Volt |
| Grinding spindle motor | 11 kW |
| Total power required | 25 kW |
| Machine's weight about | 6500 kg |
| Overall dimensions machine: | |
| Length | 3950 mm |
| Width | 2935 mm |
| Height | 2540 mm |
