LAMBERT WAHLI W 91
Type: W 91
Manufacturer: LAMBERT WAHLI
Group: Hobbing machine
Subgroup: Hobbing machine
Stock: 023513
LAMBERT WAHLI W 91 is a Hobbing machine of high precision, engineered for very accurate and reliable gear cutting. Capacities: module 0.05–1.5 mm, centre distance 40 mm, max workpiece Ø 50 mm, max cutting length 60 mm, teeth 6–390, head swivel ±5°, max cutter Ø 32 mm, cutter travel 16 mm. Specs: cutter speeds stepless up to 4500 rpm, workpiece spindle 500 rpm, supply 50 Hz 3×400 V, total power 4 kVA, weight ≈680 kg, dimensions 720×765×1445 mm. Achieves tight tolerances; typical sectors: automotive, watchmaking, machine tools, aerospace, medical.
| Module min. | 0.05 mm |
| Module max. | 1.5 mm |
| Distance between centres | 40 mm |
| Max. work piece diameter | 50 mm |
| Longueur maxi. de taillage | 60 mm |
| Pitch min. | 6 |
| Pitch max. | 390 |
| Swivelling range of the working head | +/- 5 ° |
| Max. milling cutter diameter | 32 mm |
| Max. milling cutter displac. | 16 mm |
| Milling cutter speeds: | |
| stepless | |
| up to | 4500 t/min |
| Work piece spindle speed | 500 t/min |
| Voltage 50 Hz 3x | 400 Volt |
| Total power required | 4 kVA |
| Machine's weight about | 680 kg |
| Overall dimensions machine: | |
| Length | 720 mm |
| Width | 765 mm |
| Height | 1445 mm |
