ESCO ESCOMATIC D 6 SR
Download technical sheet (PDF)
Need Assistance? Just WhatsApp Us!
ESCO ESCOMATIC D 6 SR is an automatic lathe engineered for precision, high accuracy and reliability. Capacities: with flat cam turning length 62 mm; spindle hole 6 mm; 3 turning cutters; turret 1a (D6-8-Mp 103/a) with 4 tools. Specs: 3 spindle speeds 2400–6000 rpm; voltage (60Hz) 220/440 V; total power 2.5 CV; weight ~1150 kg; dimensions L1500×W1000 mm. Equipment: integrated turret and flat cam. Delivers tight tolerances; typical applications: automotive, watchmaking, machine tools, aerospace, medical.
| Max. turning length: | |
| with flat cames | 62 mm |
| Spindle hole | 6 mm |
| Number of tool cutters | 3 |
| Spindle speeds: | |
| Number of spindle speeds | 3 |
| from | 2400 t/min |
| up to | 6000 t/min |
| Turret slide: | 1a (D6-8-Mp 103/a) |
| number of tools | 4 |
| Voltage | (60Hz) 220/440 Volt |
| Total power required | 2.5 CV |
| Machine's weight about | 1150 kg |
| Overall dimensions machine: | |
| Length | 1500 mm |
| Width | 1000 mm |
