HAUSER 3 DR is a Jig boring machine of high precision, designed for excellent accuracy and reliability. Working capacities: table 550x320 mm, max load 400 kg; travels X400 mm, Y250 mm, Z400 mm; drill capacity in steel 20 mm; max bore Ø75 mm; table‑to‑spindle 590 mm; spindle stroke 130 mm. Main specs: spindle taper MT 2; stepless speeds from 60 to 3000 t/min; spindle motor 1 CV; power 3x380 V 50 Hz; machine weight ≈1100 kg; dims L1200xW1150xH1650 mm; feeds with 2 steps. Equipment: 3‑axis digital readout (PHILIPS), rotary table Ø380 mm. Achieves tight tolerances; typical for automotive, aerospace, watchmaking, medical and toolmaking industries.
| Table length | 550 mm |
| Table width | 320 mm |
| Table load max. | 400 kg |
| Longitudinal travel (X-axis) | 400 mm |
| Transversal travel (y-axis) | 250 mm |
| Vertical travel (z axis) | 400 mm |
| Drill capacity in steel | 20 mm |
| Taper in spindle: MT | 2 |
| Stroke of drilling spindle (Z-axis) | 130 mm |
| Bore diameter max. | 75 mm |
| Distance table to spindle | 590 mm |
| Spindle speeds: | |
| stepless | |
| from | 60 t/min |
| up to | 3000 t/min |
| Feeds: | |
| Drill spindle slide: | |
| number (steps) | 2 |
| from | mm/t |
| up to | mm/t |
| Voltage 50 Hz 3x | 380 Volt |
| Spindle motor | 1 CV |
| Machine's weight about | 1100 kg |
| Overall dimensions machine: | |
| Length | 1200 mm |
| Width | 1150 mm |
| Height | 1650 mm |
| Various accessories: | |
| Digital readout number of axis: | 3 |
| Manufacturer | PHILIPS |
| Rotary table diameter | 380 mm |
