SCHAUBLIN 60 CNC
Download technical sheet (PDF)
Need Assistance? Just WhatsApp Us!
SCHAUBLIN 60 CNC is a Vertical machining center of high precision, engineered for superior accuracy and reliability. Working capacities: 3 axes; table 750 x 510 mm; table load max 700 kg; travels X600 / Y510 / Z510 mm; spindle nose BT40; spindle‑nose to table 155–665 mm. Main specs: spindle up to 8000 t/min; spindle power 13 kW; rapid traverse 30 m/min; voltage 50 Hz 3x 400 V; machine weight ~4320 kg; dimensions L2150 x W2470 x H2580 mm. Delivers tight tolerances; suitable for automotive, aerospace, medical, watchmaking and machine tool industries
Technical specifications are subject to change without notice
| Number of axis total | 3 |
| Table length | 750 mm |
| Table width | 510 mm |
| Table load max. | 700 kg |
| Longitudinal travel (X-axis) | 600 mm |
| Transversal travel (y-axis) | 510 mm |
| Vertical travel (z axis) | 510 mm |
| Spindle nose: BT | 40 |
| Distance spindle nose to table | 155 - 665 mm |
| Spindle speeds: | |
| up to | 8000 t/min |
| Rapid traverse: | 30 m/min |
| Voltage 50 Hz 3x | 400 Volt |
| Spindle power | 13 kW |
| Machine's weight about | 4320 kg |
| Overall dimensions machine: | |
| Length | 2150 mm |
| Width | 2470 mm |
| Height | 2580 mm |
