TRIPET MUR 100 is an internal grinding machine engineered for precision, high accuracy and reliable internal finishing. Working capacities and technical specifications depend on configuration. Equipment and accessories vary by version. Enables attainment of tight tolerances and is suitable for industries such as automotive, watchmaking, machine tools, aerospace and medical.
| Min. internal grinding diameter | 1 mm |
| Max. internal grinding diameter | 15 mm |
| Grinding depth | 75 mm |
| Centre height | 60 mm |
| Distance between centres | 125 mm |
| Max. work piece diameter | 80 mm |
| Workpiece spindle speeds: | |
| stepless | |
| from | 150 t/min |
| up to | 1500 t/min |
| Spindle hole | 12 mm |
| Possible grinding-spindle speeds: | |
| up to | 120000 t/min |
| Grinding table travel: | |
| max | 225 mm |
| Table speeds: | |
| stepless | |
| from | 1 m/min |
| up to | 8 m/min |
| Voltage 50 Hz 3x | 380 Volt |
| Workpiece spindle motor | 0.3 kW |
| Machine's weight about | 650 kg |
| Overall dimensions machine: | |
| Length | 1200 mm |
| Width | 1150 mm |
| Height | 1500 mm |
