ACIERA F 3 S is a universal milling machine, providing precision, high accuracy and reliable operation. Table 600x210 mm; travels X 300 mm, Y 135 mm, Z 300 mm. Spindle 8 steps up to 1500 rpm, taper 20 W. Feeds 8 steps 12–232 mm/min. Supply 3x380 V 50 Hz; motor 2.0 CV. Footprint 1100x900x1600 mm; weight approx. 620 kg. Enables machining to tight tolerances; suited for automotive, watchmaking, toolmaking, aerospace and medical sectors.
Technical specifications are subject to change without notice
| Table length | 600 mm |
| Table width | 210 mm |
| Longitudinal travel (X-axis) | 300 mm |
| Transversal travel (y axis) | 135 mm |
| Vertical travel (z axis) | 300 mm |
| Spindle speeds: | |
| number (steps) | 8 |
| up to | 1500 t/min |
| Taper in spindle: | 20 W |
| Feeds steps: | 8 |
| longitudinal from | 12.0 mm/min |
| up to | 232 mm/min |
| Voltage 50 Hz 3x | 380 Volt |
| Motor output | 2.0 CV |
| Machine's weight about | 620 kg |
| Overall dimensions machine: | |
| Length | 1100 mm |
| Width | 900 mm |
| Height | 1600 mm |
