MIKRON HSM 800 ProdMod
Download technical sheet (PDF)
Need Assistance? Just WhatsApp Us!
MIKRON HSM 800 ProdMod is a Vertical machining center engineered for precision, high accuracy and reliability. Working capacities: table 900×600 mm, max table load 800 kg; travels X800 × Y600 × Z500 mm. Main specs: spindle motor 12.5/22 kW, total power 26 kW, 3x 400 V 50 Hz, noise 75 dB(A), machine weight ≈8300 kg, dimensions L4000×W3700×H2500 mm. Equipment: 50‑position tool magazine (tool Ø max 75 mm, length 210 mm, max tool weight 2.5 kg). Delivers tight tolerances; typical applications: automotive, aerospace, medical, machine tools and watchmaking.
| Number of axis simultaneous | 4 |
| Table length | 900 mm |
| Table width | 600 mm |
| Table load max. | 800 kg |
| Longitudinal travel (X-axis) | 800 mm |
| Transversal travel (y-axis) | 600 mm |
| Vertical travel (z axis) | 500 mm |
| Tool magazine number of tool places | 50 |
| Tool diameter max. | 75 mm |
| Tool lenght | 210 mm |
| Max. tool-weight | 2.5 kg |
| Voltage 50 Hz 3x | 400 Volt |
| Spindle motor | 12.5 / 22 kW |
| Total power required | 26 kW |
| Noise level | 75 dB (A) |
| Machine's weight about | 8300 kg |
| Overall dimensions machine: | |
| Length | 4000 mm |
| Width | 3700 mm |
| Height | 2500 mm |
