KIRA KN 40 VB is a 3-axis machining center, engineered for precision, high accuracy and reliability. Working capacities: table 700×400 mm, travels X600 Y400 Z400 mm, table load max 200 kg. Technical specs: spindle nose BT40, stepless speeds 160–8000 t/min, spindle motor 7.5 kW, rapid traverse X/Y 48 m/min, Z 36 m/min, total power 11 kVA, machine weight ≈3000 kg, dimensions 2360×1600×2400 mm. Equipment: 20-position tool magazine, tool Ø max 100 mm, length 250 mm, tool weight max 5 kg, tool change time 1.2/2.8 s. Achieves tight tolerances; typical sectors: automotive, aerospace, medical, watchmaking, machine tools
| Number of axis total | 4 |
| Table length | 700 mm |
| Table width | 400 mm |
| Longitudinal travel (X-axis) | 600 mm |
| Transversal travel (y-axis) | 400 mm |
| Vertical travel (z axis) | 400 mm |
| Table load max. | 200 kg |
| Tool changer: | |
| Number of tools | 20 |
| Tool diameter | 100 mm |
| Tool lenght | 250 mm |
| Max. tool-weight | 5 kg |
| Time of tool changing | 1.2 / 2.8 s |
| Spindle nose: | BT 40 |
| Vertical spindle speeds: | |
| stepless | |
| from | 160 t/min |
| up to | 8000 t/min |
| Rapid traverse: long. | 48 m/min |
| Rapid traverse: transversal | 48 m/min |
| Rapid traverse: vertical | 36 m/min |
| Spindle motor | 7.5 kW |
| Total power required | 11 kVA |
| Machine's weight about | 3000 kg |
| Overall dimensions machine: | |
| Length | 2360 mm |
| Width | 1600 mm |
| Height | 2400 mm |
