PEMAMO MDR 140 EH
Download technical sheet (PDF)
Need Assistance? Just WhatsApp Us!
PEMAMO MDR 140 EH is a honing machine delivering high precision, accuracy and reliability. Capacities: Ø 2–50 mm; stroke 120 mm; spindle speeds 150–2500 t/min; stroke speed up to 220 c/min. Power: 50 Hz 3×400 V; spindle motor 2.2 kW; total 4 kVA; size 1600×1000×1600 mm; weight ≈900 kg. Fitted with coolant system, paper filtration and foot pedal. Achieves tight tolerances; ideal for automotive, watchmaking, machine tools, aerospace and medical.
| Min. diameter | 2 mm |
| Max. diameter | 50 mm |
| Spindle speeds: | |
| from | 150 t/min |
| up to | 2500 t/min |
| Total stroke | 120 mm |
| Stroke speed: | |
| from | c/min |
| up to | 220 c/min |
| Voltage 50 Hz 3x | 400 Volt |
| Spindle motor | 2.2 kW |
| Total power required | 4 kVA |
| Machine's weight about | 900 kg |
| Overall dimensions machine: | |
| Length | 1600 mm |
| Width | 1000 mm |
| Height | 1600 mm |
| Various accessories: | |
| Coolant system | |
| Paper filtration system | |
| Foot pedal |
