TORNOS R 10 is an automatic lathe, engineered for precision, high accuracy and reliability. Working capacities: diameter of work admitted 10 mm; spindle hole 13 mm; max treading diameter 8 M; max turning length with flat cames 70 mm, with bell cames 100 mm; number of tool cutters 5. Main technical specifications: 20 spindle speeds from 1050 to 8000 t/min; voltage 50 Hz 3x 380 Volt; total power required 3 CV; machine weight about 860 kg; overall dimensions L1500×W750×H1450 mm. Accessories: 3‑spindle drilling attachment, protective cover, rocker arm with 1/1000 mm. Enables tight tolerances; typical application sectors: automotive, watchmaking, machine tools, aerospace and medical.
| Diameter of work admitted | 10 mm |
| Max. turning length: | |
| with flat cames | 70 mm |
| with bell cames | 100 mm |
| Spindle hole | 13 mm |
| Max. treading diameter | 8 M |
| Number of tool cutters | 5 |
| Spindle speeds: | |
| Number of spindle speeds | 20 |
| from | 1050 t/min |
| up to | 8000 t/min |
| Voltage 50 Hz 3x | 380 Volt |
| Total power required | 3 CV |
| Machine's weight about | 860 kg |
| Overall dimensions machine: | |
| Length | 1500 mm |
| Width | 750 mm |
| Height | 1450 mm |
| Various accessories: | |
| 3-spindle drilling attachment | |
| Protective cover | |
| Rocker arm with 1/1000 mm |
