TSCHUDIN GL 600 is a CNC centerless grinding machine designed for precision, high accuracy and reliable operation. Working capacities: grinding diameter 2–100 mm; grinding wheel Ø600 mm × 350 mm; regulating wheel Ø350 mm × 350 mm, swivelling range ±5°. Key specs: grinding spindle stepless, speeds up to 45 m/s; regulating spindle stepless 0–290 t/min; voltage 50 Hz 3x400 V; grinding motor 22 kW; total power 26 kVA; overall dimensions L2300 × W2000 × H2150 mm. Enables tight tolerances; suitable for automotive, watchmaking, machine tools, aerospace and medical sectors
| Min. grinding diameter | 2 mm |
| Max. grinding diameter | 100 mm |
| Grinding wheel: | |
| Diameter | 600 mm |
| Width | 350 mm |
| Speeds: | |
| stepless | |
| from | m/s |
| up to | 45 m/s |
| Regulating spindle: | |
| Diameter | 350 mm |
| Width | 350 mm |
| Swivelling range | +/-5 ° |
| Speeds: | |
| stepless | |
| from | 0 t/min |
| up to | 290 t/min |
| Voltage 50 Hz 3x | 400 Volt |
| grinding motor | 22 kW |
| Total power required | 26 kVA |
| Overall dimensions machine: | |
| Length | 2300 mm |
| Width | 2000 mm |
| Height | 2150 mm |
