SPINNER VC-560 is a 3-axis machining center, engineered for precision, high accuracy and reliability. Table 650x410 mm, 3 T-channels 14 mm, table load max 250 kg; travels X560 Y410 Z410 mm. Spindle SK40, 0–12,000 rpm (stepless), rapid traverse 48 m/min. Tool magazine 24 places, tool Ø max 77 mm (125 mm with free adjacent pockets), tool length 200 mm, max tool weight 5 kg, tool change 1.3 s. Power 3x400 V 50 Hz, total power 30 kW; machine weight ~4000 kg; overall L3000 x W2000 x H2500 mm. Delivers tight tolerances; suited for automotive, aerospace, medical, watchmaking and machine-tool industries
| Number of axis total | 3 |
| Table length | 650 mm |
| Table width | 410 mm |
| Number of T-channels | 3 |
| T-channel width | 14 mm |
| Table load max. | 250 kg |
| Longitudinal travel (X-axis) | 560 mm |
| Transversal travel (y-axis) | 410 mm |
| Vertical travel (z axis) | 410 mm |
| Tool magazine number of tool places | 24 |
| Tool diameter max. | 77 mm |
| Diameter with free adjacent pockets | 125 mm |
| Tool lenght | 200 mm |
| Max. tool-weight | 5 kg |
| Time of tool changing | 1.3 s |
| Spindle nose SK | 40 |
| Spindle speeds: | |
| stepless | |
| from | 0 t/min |
| up to | 12000 t/min |
| Rapid traverse: | 48 m/min |
| Voltage 50 Hz 3x | 400 Volt |
| Total power required | 30 kW |
| Machine's weight about | 4000 kg |
| Overall dimensions machine: | |
| Length | 3000 mm |
| Width | 2000 mm |
| Height | 2500 mm |
