AGATHON 175 AR is a Tool grinding machine offering precision, high accuracy and reliable performance. Capacities: grinding wheel Ø175 mm × width 35 mm, bore 20 mm; tool clamping up to W32×H32 mm. Specs: spindle speed from 2800 t/min; 50 Hz 3x 380 V supply; power 1.0 CV; weight approx. 300 kg; dimensions 1000×650×1400 mm. Accessories: inclinable tool holder, coolant system, lamp. Enables tight tolerances; typical applications: automotive, machine tools, aerospace, medical, watchmaking.
| Grinding wheels: | |
| Diameter | 175 mm |
| Width | 35 mm |
| Bore | 20 mm |
| Spindle speeds: | |
| from | 2800 t/min |
| Clamping range of the tools: | |
| Width | 32 mm |
| Height | 32 mm |
| Voltage 50 Hz 3x | 380 Volt |
| Power | 1.0 CV |
| Machine's weight about | 300 kg |
| Overall dimensions machine: | |
| Length | 1000 mm |
| Width | 650 mm |
| Height | 1400 mm |
| Various accessories: | |
| Inclinable tool holder | |
| Coolant system | |
| Lamp |
