SIXIS S 101 is a Universal milling machine designed for precision, high accuracy and reliability. Longitudinal travel X 150 mm, Transversal Y 100 mm, Vertical Z 150 mm; spindle with 6 steps from 125 to 4000 t/min, spindle taper 12 W. Voltage 50 Hz 3x 380 V; machine weight approx. 120 kg; overall dimensions L1500 x W700 x H620 mm. Fitted with a vice (jaw width 60 mm), rigid table, vertical milling head and lamp. Delivers tight tolerances; typical applications include automotive, watchmaking, machine tools, aerospace and medical.
| Longitudinal travel (X-axis) | 150 mm |
| Transversal travel (y axis) | 100 mm |
| Vertical travel (z axis) | 150 mm |
| Spindle speeds: | |
| number (steps) | 6 |
| from | 125 t/min |
| up to | 4000 t/min |
| Taper in spindle: | 12 W |
| Voltage 50 Hz 3x | 380 Volt |
| Machine's weight about | 120 kg |
| Overall dimensions machine: | |
| Length | 1500 mm |
| Width | 700 mm |
| Height | 620 mm |
| Various accessories: | |
| Vice: width | 60 mm |
| Rigide table | |
| Vertical milling head | |
| Lamp |
