SIXIS S 101 is a Universal milling machine, designed for precision, high accuracy and reliability. Table 300×120 mm, 3 T‑slots 8 mm (spacing 40 mm); travels X150 Y100 Z150 mm. Spindle 6 steps 125–4000 rpm, taper 12 W; power 3x380 V 50 Hz; motor 0.3 CV; total installed 1 CV. Weight ~150 kg; dimensions 1100×750×1400 mm. Accessories: vice (jaw width 80 mm), tilting/swivel table, lamp. Delivers tight tolerances; typical sectors: automotive, watchmaking, machine tools, aerospace, medical.
| Table length | 300 mm |
| Table width | 120 mm |
| Number of T-channels | 3 |
| T-channel width | 8 mm |
| Distance of the T-slots | 40 mm |
| Longitudinal travel (X-axis) | 150 mm |
| Transversal travel (y axis) | 100 mm |
| Vertical travel (z axis) | 150 mm |
| Spindle speeds: | |
| number (steps) | 6 |
| from | 125 t/min |
| up to | 4000 t/min |
| Taper in spindle: | 12 W |
| Voltage 50 Hz 3x | 380 Volt |
| Motor output | 0.3 CV |
| Total power required | 1 CV |
| Machine's weight about | 150 kg |
| Overall dimensions machine: | |
| Length | 1100 mm |
| Width | 750 mm |
| Height | 1400 mm |
| Various accessories: | |
| Vice: width | 80 mm |
| Tilting and swivel table | |
| Lamp |
